260pcs/Min Printer Slotter Die Cutter Machine For Carton Box Packing Line

HEBEI SOOME PACKAGING MACHINERY CO.,LTD
Contact Now

260pcs/Min Printer Slotter Die Cutter Machine For Carton Box Packing Line

Brand Name : SOOME

Model Number : SMYS-1224

Certification : CE

Place of Origin : China

MOQ : 1 Set

Price : Contact

Payment Terms : L/C, T/T

Supply Ability : 20 Sets/Month

Delivery Time : 45 Days

Packaging Details : Wooden case or plastic film;3*40'Container

Usage : Printing carton box

Speed : 260pcs/min

Colors : 2-6

Voltage : 380V or as you need

Max.paper size : 1200*2400mm

Min.paper size : 300*600mm

Feeder paper type : Automatic lead edge feeder

Keyword : Corrugated printing machine

Contact Now

1224 Model 260Pcs/min Automatic Pizza Box Printer Die Cutter Machine Packing Line

Carton pizza box printer slotter die cutter machine is a printing equipment that can print the required words, patterns and other information to the surface of the carton box. It generally includes plate loading, inking, embossing, paper feeding and other processes. Carton printing generally has single printing, printing belt slotting/die cutting, printing slotting/die cutting, sticky box and linkage production line.

Working principle:

Carton pizza box printer slotter die cutter machine will first print the text and image into a printing plate, installed on the printing machine, and then by the operator of the printing machine to evenly spread the ink on the printing plate where there are words and images, and then directly or indirectly transferred to corrugated board or carton, so as to copy the same printing copy with the printing plate.

Whole machine character:

1 . It adopts the computer to control the storage order with changing the lists quick and convenient

2 . All of the transmission gears and rollers adopt good quality steel with heat treatment and grinding.

3 . All of the units printer slotter die cutter machine with alarm ringing , each unit sets a sudden stop switch to ensure the safety of the operator.

4 . The balance device of the engine oil

5 . All drive rollers are high quality steel, hard chrome plated, surface grinding

6 . Printer slotter die cutter machine the wall plate is high quality steel, which is processed by CNC machining center after stress removal

7 . Paint spraying process: before painting, parts through the de-rusting - phosphating - spray - paint - baking paint, so that the paint rust, hard surface, paint more durable

8 . All of the units marches with alarm ringing , each unit sets a sudden stop switch to ensure the safety of the operator.

9 . Machine with large screen display table, display the machine printing speed (by pcs/hour), convenient for operating personnel in different directions machine is easy to see the running speed of the machine.

10 . Lubricating oil automatic balancing device to keep all units of lubricating oil on the same horizontal line

11 . The computer control system can store up to 999 orders.

12 . Automatic zero function.

Corrugated pizza box printing die cutting with slotting technical parameters :

NO. Parameter name Unit Model
1 Design speed Piece/min 260
2 The maximum size feeding paper mm 1200x2400
3 The minimum size feeding paper mm 300x600
4 The maximum size of feeding paper by partition mm 1500x2400
5 The maximum size of printing area mm 1200x2360
6 Printing precision mm ±0.5
7 Standard plate thickness mm 7.2
8 Printing paperboard thickness range mm 2-11
9 Printing roller adjustment

degree

360°
10 Printing roller lateral adjustment mm ±10
11 Slotting precision mm ±1
12 Minimum slotting distance(opposite direction) mm 230x65x230x65
13 Maximum slotting depth mm 300
